CCS2 to GB/T V2.0 DC Fast-Charge Adapter (400A)
DC fast-charge a GB/T-standard EV from a compatible CCS2 rapid charger. This adapter makes that connection, and it's built for serious power: up to 400A and 1000V DC. Actual charging performance depends on the vehicle and charging station.
The reinforced construction weighs 2.38kg, with IP54 protection after coupling and a -30°C to +50°C operating temperature range. Built-in temperature protection automatically shuts down
Additional features include a dual-end locking mechanism, durability exceeding 10,000 no-load mating cycles, and Bluetooth connectivity through the LSC app with charging information, charging history, software upgrades and log management.
Works with: GB/T-standard vehicles charging from compatible CCS2 DC rapid stations.
IMPORTANT NOTICE: Always confirm your vehicle’s charging connector, AC/DC charging specifications, supported voltage, current, and maximum charging power, as these may vary by model, model year, and market. Charging compatibility and performance depend on the vehicle and charging source. For AC charging: also confirm your vehicle’s On-Board Charger (OBC) capability.
Technical Specifications
CCS2 to GB/T V2.0 DC Fast-Charge Adapter (400A)
Every detail you need to confirm the right fit, from connector standards and power ratings to protection and operating range.
DC
For GB/T-standard EVs (common on imported Chinese-market vehicles) DC fast-charging from CCS2 rapid chargers.
400A DC max
1000V DC max
IP54
-30°C to +50°C
2.1 kg
294.38 × 95.48 × 145.39 mm
CE / IEC 62196-3
1 year
